Now available for pre-order! The Brewtools FCS Starter Kit with Density Sensor will be released in late July. Place your pre-order today to lock in priority order fulfillment as soon as the unit is available.
-
Density sensor with integrated temperature sensor for FCS gives accurate and real-time density and temperature data for your fermentation tank
-
Measures density by inducing a vibration frequency in the fork and listening for the resonant frequency
-
Primarily designed for fermentation tanks like the F40-F300 and similar tanks
Tuning fork-based measurements gives accurate and real-time density and temperature data for your fermentation tank. The Brewtools density sensor measures density by inducing a vibration frequency in the fork and listening for the resonant frequency.
Take your fermentation to the next level with data-driven control and logging. Future updates of FCS will enable you to control temperature and pressure steps based on density in the tank, without the need for manual intervention.
This model is primarily designed for fermentation tanks like our F40-F300 and similar tanks. Accuracy may vary for smaller tanks (like MiniUni+).
More information: https://docs.brewtools.com/density-sensor
Specifications:
-
Density accuracy: +-0.002 SG
-
Temperature accuracy: +- 0.3ºC
-
Flange: TC 1.5". Ø25mm minimum
-
Length: 200mm from flange
-
Connector: LP12 5-pin (CAN bus + 24V)
Note: Accuracy and function can vary based on trub, yeast health, yeast flocculation, rapid temperature changes, dry-hopping and other additions and distance to tank wall/heating elements etc. Pressure fermentation can increase accuracy. Accuracy and features will improve over time with software updates.
Brewtools Product Number: 7713723
