Kreyer Fan Unit | SD-S 35 | 1.6 Ton Cooling Capacity | Single Fan | For Rooms Up To 17,500 ft³ | 230V

    Description

    Due to high demand, this item is currently out of stock. Be the first to receive your items by placing a pre-order today. We will automatically ship this to you when we receive more inventory.

    • Use your existing glycol system to cool your cellar
    • Eliminates the need to purchase an entirely separate refrigeration system
    • SD-S series fan units were designed specifically for high-moisture environments like wine cellars
    • Sized for well-insulated rooms up to 17,500 ft³
    • Made in Germany by Kreyer

    Cool your cellar using your existing glycol system. Save energy and money! These units work under the same principles as standard refrigeration but use cooled glycol that you already have instead of cooled refrigerant gas, eliminating the need to have a separate refrigeration system. It is a fantastic use of your glycol system for a majority of the year when typically glycol systems are on but are being sporadically called upon. Glycol systems do need to be sized to accommodate both these fan units and peak duty during the crush to be able to accommodate all tasks at once.

    Glycol from your main glycol chiller is recirculated through these fan units. Aluminum fins act as heat exchangers drawing heat out of your room as the fins are cooled by the glycol. If you have a Kreyer chiller/heater you can even heat a space in cold weather environments.

    The heat exchangers inside the units are made from corrugated aluminum fins and internally grooved copper tubes. The white ABS casing looks great. Because of its rounded corners it has no water retaining areas favorable to germ development. Both series are fitted with stainless steel screws and show no sharp, cutting edges.

    The SD-S series has been designed especially for problematic environments such as wine-cellars with high moisture. The high-performance fans on the SD-S unit are lubricated for life.

    The SD-S 35 is sized to:
    Cool a room up to 17,500 when the ceiling and walls are well insulated. Cooling a room this size from 90F to 60F will use approximately 1.05 tons of cooling power from your chilling system. If the room is half insulated you will need approximately 50% more power or 1.6 tons of cooling power. Once you've achieved the desired temperature it takes considerably less power to maintain it.

    Fan Unit Temp Control Upgrades:

    • 3/4 in. Solenoid Valve - Allows or blocks flow of glycol through the fan unit. Needs to be connected to a Controller to function. A filter is recommended to protect the solenoid.
    • 3/4 in. Solenoid Filter- protects the solenoid valve from any particulate or sediment.
    • Glycol Fan Control Unit - Set a specific temperature on this controller and it will open and close the solenoid valve.
    • Solenoid Connection Cable - This 2 meter long cable is required to connect the Solenoid Valve & Control unit.

    Inlet and Outlet: 3/4" Male BSP

    Please Note: This unit only has one fan. The weight shown below is for shipping purposes, as this item ships at an oversize rate with UPS Ground. Actual weight of the fan is about 35lb. Actual Dimensions are 710x410x460mm



    Kreyer Fan Unit | SD-S 35 | 1.6 Ton Cooling Capacity | Single Fan | For Rooms Up To 17,500 ft³ | 230V

      Product form

      SKU: SDS35L

      $1,774.99

      Shipping
      Free Shipping*
      Shipping
      Paid Shipping
      Drop Ship
      Drop Ship
      Discount Exclusion
      Discount Exclusion
      Freight
      Freight Only
      Pre-book
      Pre Order

        WARNING : This product can expose you to chemicals including Lead and lead compounds, which is/are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to www.p65warnings.ca.gov.

        Description

        Due to high demand, this item is currently out of stock. Be the first to receive your items by placing a pre-order today. We will automatically ship this to you when we receive more inventory.

        • Use your existing glycol system to cool your cellar
        • Eliminates the need to purchase an entirely separate refrigeration system
        • SD-S series fan units were designed specifically for high-moisture environments like wine cellars
        • Sized for well-insulated rooms up to 17,500 ft³
        • Made in Germany by Kreyer

        Cool your cellar using your existing glycol system. Save energy and money! These units work under the same principles as standard refrigeration but use cooled glycol that you already have instead of cooled refrigerant gas, eliminating the need to have a separate refrigeration system. It is a fantastic use of your glycol system for a majority of the year when typically glycol systems are on but are being sporadically called upon. Glycol systems do need to be sized to accommodate both these fan units and peak duty during the crush to be able to accommodate all tasks at once.

        Glycol from your main glycol chiller is recirculated through these fan units. Aluminum fins act as heat exchangers drawing heat out of your room as the fins are cooled by the glycol. If you have a Kreyer chiller/heater you can even heat a space in cold weather environments.

        The heat exchangers inside the units are made from corrugated aluminum fins and internally grooved copper tubes. The white ABS casing looks great. Because of its rounded corners it has no water retaining areas favorable to germ development. Both series are fitted with stainless steel screws and show no sharp, cutting edges.

        The SD-S series has been designed especially for problematic environments such as wine-cellars with high moisture. The high-performance fans on the SD-S unit are lubricated for life.

        The SD-S 35 is sized to:
        Cool a room up to 17,500 when the ceiling and walls are well insulated. Cooling a room this size from 90F to 60F will use approximately 1.05 tons of cooling power from your chilling system. If the room is half insulated you will need approximately 50% more power or 1.6 tons of cooling power. Once you've achieved the desired temperature it takes considerably less power to maintain it.

        Fan Unit Temp Control Upgrades:

        • 3/4 in. Solenoid Valve - Allows or blocks flow of glycol through the fan unit. Needs to be connected to a Controller to function. A filter is recommended to protect the solenoid.
        • 3/4 in. Solenoid Filter- protects the solenoid valve from any particulate or sediment.
        • Glycol Fan Control Unit - Set a specific temperature on this controller and it will open and close the solenoid valve.
        • Solenoid Connection Cable - This 2 meter long cable is required to connect the Solenoid Valve & Control unit.

        Inlet and Outlet: 3/4" Male BSP

        Please Note: This unit only has one fan. The weight shown below is for shipping purposes, as this item ships at an oversize rate with UPS Ground. Actual weight of the fan is about 35lb. Actual Dimensions are 710x410x460mm



        Documents
        Scheme FermFlex-Room GB
        SD-S Fan Information Sheet
        SD-S Installation Instructions
        Wiring
        Wiring Fan Unit to GLY980 Controller
        Important Warnings & Shipping Info +
        Shipping Icon
        Free Shipping: Fast & Free Shipping over $79
        Shipping Icon
        Shipping Rates Apply: Bulk items like grain, bottles, and malt are excluded from our free shipping promotion due to their weight, and often dropship items. Standard shipping rates apply and are calculated at checkout based on your location and order size.
        Drop Ship Icon
        Drop Ship: This product will ship directly from the supplier. Delivery may take 1-4 weeks depending on the vendor.
        Discount Exclusion Icon
        Discount Exclusion: This item is not eligible for sitewide price reductions or percentage discounts.
        Freight Icon
        Freight Shipping: This item ships freight only.
        Pre-book Icon
        Pre Order: This item is available for Pre-Order. Full payment is required to reserve stock.
        Shipping Weight: 43.1 lb
